What are the types of flow meters? Flow meter is one of the indispensable instruments in industrial measurement. With the development of industrial production, the requirements for accuracy and range of flow measurement are becoming increasingly high, and flow measurement technology is also constantly improving. Currently, over 100 types of flow meters have been put into use. According to different classification methods, flow meters can be classified into multiple types.
1. Classification by measurement principle 1 Mechanics principles: including differential pressure, rotor, impulse, movable tube, mass, target, turbine, pitot tube, volumetric and weir, trough flow meters, etc.
2. Electrical principles: such as electric magnetic flowmeter, differential capacitive flowmeter, inductive flowmeter, strain resistance flowmeter, etc.
3. Acoustic principles: ultrasonic flowmeter, acoustic (shock wave) flowmeter, etc.
4. Thermal principles: thermal flowmeter, direct opening calorimeter, indirect calorimeter flowmeter, etc.
5. Optical principles: laser flowmeter, photoelectric flowmeter, etc.
6. Atomic physics principles 7. Other principles such as labeling principle (tracer principle, nuclear magnetic resonance principle), related principles, etc.
2. Classification according to the principle of flowmeter structure 1 Positive displacement flow meters: such as elliptical gear flow meters, waist wheel flow meters (Roots flow meters), rotary piston and scraper flow meters, etc.
2. Blade type flow meters: such as water meters, turbine flow meters, etc.
3. Differential pressure flow meters (variable pressure drop flow meters): such as throttling devices or dynamic pressure m
4. Variable area flow meters (constant pressure drop flow meters): such as rotor (float) flow meters, etc.
5. Momentum flow meters: such as target and rotary vane flow meters, etc.
6. Impulse flow meters: such as horizontal force impulse flow meters, etc.
7. Electromagnetic flowmeter: suitable for media with low conductivity, such as water, slurry, etc.
8. Ultrasonic flowmeter: can be made into a non-contact type and can be linked with an ultrasonic water level gauge for open flow measurement. 9. Fluid oscillating flowmeter: such as vortex flowmeter, vortex flowmeter, etc. 10. Mass flowmeter: There are two types: direct and indirect, such as calorimetry, angular momentum, vibration gyroscope, Magnus effect, and Coriolis force. The above are some commonly used types of flow meters. With the development of technology and the needs of practical applications, new types of flow meters will continue to emerge, and the types of flow meters will become more diverse.
2. What are the classifications and principles of flow meters?
Based on the actual situation of current flow meter products and the needs of industrial production, and according to the structural principles of flow meters, commonly used flow meters can be roughly classified into the following types:
1. Common types of flow meters (positive displacement flow meters) A positive displacement flow meter is equivalent to a standard volume container that continuously measures the flowing medium.
. The larger the traffic, the more times it is measured, and the higher the output frequency. The principle of volumetric flowmeter is relatively simple and suitable f
