Gryvoze Flow Meter: Sourcing Inline Mechanical Fuel and Water Trackers
Quick Answer: Silver Automation Instruments supplies the Gryvoze flow meter series for inline mechanical fuel and water tracking. These meters give a local mechanical total, need no external power, and suit DN15 to DN50 lines. Send your pipe size (DN), fluid type, flow range, and thread standard to get a quote.
Why Buyers Use Gryvoze Inline Mechanical Flow Meters
Sourcing a mechanical fuel or water tracker often starts with a simple list. You need a meter that fits the pipe, reads locally, and does not stop when power fails. The Gryvoze flow meter range covers diesel, water, and light oils in DN15, DN20, DN25, DN40, and DN50 sizes. Buyers in Southeast Asia, the Middle East, Africa, and Latin America use these meters on day tanks, boiler feed lines, cooling water skids, and small fuel distribution trailers.
Here is the thing. An inline mechanical meter is not a complicated device. But the wrong body material or thread type will delay a project. We have seen this on customer sites many times. A diesel user in the Philippines asked for a DN25 meter with NPT threads. The installation team had BSP fittings on site. The meter body was correct, but the thread mismatch added two days of rework.
Common Fuel and Water Tracking Applications
Gryvoze inline mechanical flow meters work well for small and mid size batching jobs. Fuel distributors use them on diesel transfer pumps. Water treatment operators install them on chemical dilution lines. Marine workshops use them for bilge water tracking. A paint manufacturer in Vietnam needed a water tracker for a 25 mm cooling line. The meter had to survive a humid site, read clearly through a control panel window, and hold accuracy after six months of duty.
In practice, most users want two things. They want a repeatable batch total and a non resettable cumulative total. The mechanical register gives both. No transmitter means fewer failure points. No signal wiring means the meter can be installed in Zone 2 or unclassified areas without extra barriers. Because the counter runs on flow alone, a power cut does not lose the accumulated volume.
Mechanical Register and Local Display Details
The Gryvoze flow meter uses an oval gear or nutating disc measuring element depending on the fluid. For diesel and light fuel oil, an oval gear design handles viscosity from about 1 cP to 100 cP. For clean water, a nutating disc design is common. Accuracy is typically ±0.5 percent of reading for diesel and ±1 percent for water when installed inside the recommended flow range. The local display shows a resettable batch total and a cumulative total. A pulse output can be added for remote totalizing or PLC input. If you need a 4-20 mA signal, Silver Automation Instruments can pair the meter with a pulse to analog converter.
Most engineers skip the pulse output for simple fuel tracking. It adds cost. If the meter sits near the pump and an operator writes down the batch total each shift, the mechanical register is enough. If the site has a control room 200 metres away, request the pulse output at the quote stage.
Sizing and Connection Options_600x400.jpg)
Pipe size is the first detail to confirm. The Gryvoze flow meter is available in DN15, DN20, DN25, DN40, and DN50. Threads are BSP or NPT. Choose the material based on the fluid and site environment. Aluminum bodies suit diesel and light oils in dry locations. Stainless steel bodies are better for water, coastal sites, and food grade washdown areas. Maximum working pressure for standard sizes is 10 bar at 20 °C. The operating temperature range is -10 °C to 80 °C.
Inline installation needs a little planning. Keep the meter full of liquid. Avoid air pockets. Install a mesh strainer upstream. For diesel lines, a 60 mesh strainer is enough. For water with sand or rust, use a 100 mesh strainer. Allow five pipe diameters of straight run before the meter and three pipe diameters after. This keeps the flow profile stable and protects the measuring element from debris. In tight mechanical rooms, a compact meter body helps. The DN15 and DN20 models have a face to face length under 120 mm.
How to Get a Quote from Silver Automation Instruments
Send us your fluid type, flow range in L/min or m3/h, pipe size (DN), thread standard, and operating pressure. If you have a target accuracy, include that as well. A typical request looks like this: diesel, 5 to 60 L/min, DN25, BSP thread, 6 bar, local total only. That gives our engineers enough detail to recommend a Gryvoze flow meter and check the turndown.
You can reach Silver Automation Instruments at Tel: +86-25-68650347, Whatsapp: +86-25-52155837, or WeChat: +86 15365082610. The product page is on flow-meter.com.au. Ask for pricing on one unit for evaluation. We also support bulk orders for distributors in Southeast Asia, Latin America, Africa, and the Middle East. MOQ is one unit for standard sizes. Lead time is usually 7 to 15 days after order confirmation.
FAQ: Five Buyer Questions on Gryvoze Flow Meters
Q: What sizes are available for Gryvoze inline mechanical fuel and water trackers?
A: The standard range covers DN15, DN20, DN25, DN40, and DN50. Threads are BSP or NPT. Custom sizes above DN50 are available on request for clean water.
Q: What is the typical accuracy for diesel and water batching?
A: Diesel and light fuel oil meters have an accuracy of ±0.5 percent of reading. Water meters are normally ±1 percent of reading. Accuracy depends on viscosity, flow range, and installation conditions.
Q: Can the mechanical counter work without electricity?
A: Yes. The register runs directly from flow movement. It keeps a cumulative total during power loss. This is the main reason maintenance teams choose mechanical trackers for remote fuel skids.
Q: How do I order the right connection size and thread?
A: Measure the pipe inner diameter and confirm the thread standard. Send us the DN size, thread type, fluid, flow range, and pressure. We check the meter body, seal material, and strainer specification against that data.
Q: What is the typical lead time and MOQ for a quote?
A: MOQ is one unit for standard DN15 to DN50 sizes. Lead time is usually 7 to 15 days. For stainless steel body or pulse output versions, allow a few extra days.
