How does a differential pressure flowmeter work?

Pressure difference P=0.5-0.07=0.43MPA. If the pipe length is L and the specific resistance of the pipeline is S, then the flow rate Q=[P/(pgSL)] ^ (1/2). A differential pressure flowmeter is an instrument for measuring flow rate. It utilizes the principle that there is a certain relationship between the pressure difference and flow rate generated when the fluid flows through the throttling device, and achieves flow measurement by measuring the pressure difference. A throttling device is a local contraction element installed in a pipeline, commonly used in orifice plates, nozzles, and Venturi tubes. The calculation formula for flow Q is blind clearing: where C is the flow coefficient; ε is the gas expansion correction coefficient; F is the cross-sectional area of the throttling section; G is the acceleration due to gravity; γ is the fluid density; P1 and P2 are the pressures before and after throttling, respectively. For incompressible gases, the gas expansion correction coefficient may not be considered, and the flow rate formula is generally determined by experimental methods as C and ε. Additional information: Differential pressure flowmeter consists of a primary device and a secondary device. The primary device is called a flow measurement element, which is installed in the pipeline of the measured fluid to generate a pressure difference proportional to the flow rate (velocity) for the secondary device to display the flow rate. The secondary device is called a display instrument. It receives the differential pressure signal generated by the measuring element and converts it into the corresponding flow rate for display. The primary device of a differential p

Principle of differential pressure flowmeter

ressure flowmeter is often a throttling device or a dynamic pressure measuring device (pitot tube, averaging tube, etc.). The secondary device is equipped with various mechanical, electronic, and combination differential pressure gauges with flow display instruments. The differential pressure sensitive elements of the differential pressure gauge are mostly elastic elements. Due to the square root relationship between differential pressure and flow rate, flow display instruments are equipped with a wide square device to linearize the flow scale. Most instruments are also equipped with flow accumulation devices to display accumulated flow for economic accounting. This method of measuring flow using differential pressure has a long history and is relatively mature. It is generally used in important situations around the world, accounting for about 70% of various flow measurement methods. Reference source: Baidu Baike - Differential Pressure Flow Meter

2. Types and Principles of Flow Meters

The types of flow meters mainly include volumetric flow meters, differential pressure flow meters, float flow meters, turbine flow meters, electromagnetic flow meters, vortex flow meters (a type of fluid oscillation flow meter), mass flow meters, insertion flow meters, and probe flow meters. The following are the working principles and applications of several commonly used flow meters.

1. Principle of differential pressure flow meter: Calculate the flow rate based on the differential pressure generated by the flow detection component installed in the pipeline, combined with known fluid conditions and the geometric dimensions of the detection component and the pipeline.

. Application: Widely used for flow measurement
