Coriolis Mass Flow Meter: Legal-For-Trade Certification and Custody Transfer Standards
Quick Answer: Coriolis mass flow meters achieve legal-for-trade status by complying with OIML R117, MID, or NTEP standards. They are accepted for custody transfer of crude oil, fuels, chemicals, and LNG because they provide direct mass measurement, high accuracy, and no moving parts. Silver Instruments offers certified Coriolis meters with ATEX Zone 1 approvals and 4-20 mA HART outputs for billing applications across Southeast Asia, the Middle East, and Latin America.
What Makes a Coriolis Meter Legal for Trade
OIML R117 is the global benchmark for dynamic liquid measuring systems. Our meters pass class 0.3 or class 0.15 tests depending on the model and pipe size. Typical accuracy stays within 0.1 percent of rate over a 10:1 turndown for DN15 to DN200 sizes. Each instrument carries a type approval certificate and factory calibration with water or diesel. Certification also demands strict drift limits, temperature compensation, and communication checks. The transmitter stores calibration data and locks out unauthorized changes. Engineers at fuel depots or chemical terminals need this traceability. Without a valid certificate, the meter cannot be used for invoicing. A lubricant blender in Vietnam replaced aging positive displacement meters with our DN40 Coriolis meter. Now they run monthly reconciliation and see less than 0.05 percent unaccounted product. No more manual density corrections.
Custody Transfer Applications Where Certified Meters Are Mandatory
Marine loading arms transfer diesel, jet fuel, and gasoline into tankers. Every kilogram must be tracked for tax and contract purposes. Pipeline operators between Malaysia and Singapore rely on certified Coriolis meters to measure condensate and naphtha at 200 t/h. A palm oil exporter in Indonesia uses a DN80 meter to invoice shipments to Rotterdam. The mass reading is accepted by both buyer and seller because the meter holds MID certification. LNG bunkering operations now require custody-grade mass measurement because LNG is sold on an energy basis. Our meters with integrated density output help calculate the calorific value directly. In Brazil, ethanol mills use certified meters to record volumes for government fuel quotas. In all these cases, the meter acts as the cash register.
Key Certifications We Provide with Our Coriolis Meters
Silver Instruments supplies Coriolis flow meters with OIML R117 and MID certifications for European and Middle Eastern markets. For North American shipments we can arrange NTEP evaluation upon request. Sensor housings are available in 316L stainless steel or Hastelloy C22 for aggressive fluids. The transmitter is ATEX Zone 1 and IECEx approved for gas and dust environments. Process connections from DN15 to DN200 are standard. Accuracy class options include 0.1 percent and 0.15 percent of rate. Repeatability stays better than 0.05 percent. The electronics output 4-20 mA HART, Modbus RTU, and pulse, all with SIL2 safety certification. We include a dry calibration certifica
Real-World Performance during Custody Transfer
Here is the thing: pressure drop worries most engineers. Our Coriolis meters use twin straight tubes or slightly bent tubes to keep pressure loss under 0.5 bar at nominal flow for DN50. A fuel depot in the Philippines injected Jet A-1 through a DN100 meter at 80 cubic meters per hour. Over six months the meter held stability and matched the tank gauge within 0.08 percent. There was zero drift. Another case, a chemical trader in Dubai measured xylene with a DN25 meter. The fluid viscosity was 0.9 cP at 30 degrees Celsius. The meter handled it without recalibration. The trader avoided legal disputes because the meter was MID certified and the readings were irrefutable. These instruments also survive occasional air slugs and entrained gas thanks to the Coriolis measuring principle. Most engineers skip this part during evaluation, but it saves money on flow conditioning.
How to Specify a Legal-for-Trade Coriolis Flow Meter from Silver Instruments
Send us your fluid name, expected flow range in kg/h or t/h, operating pressure in bar, temperature in degrees Celsius, pipe size DN, and required certificate standard. We will propose a meter model with exact wetted materials, connection flanges, and hazardous area approvals. Email [email protected] or call +86-25-68650347. You can also reach us on WhatsApp at +86-25-52155837 or WeChat at +86 15365082610. We ship to Australia, Latin America, the Middle East, and Southeast Asia with full documentation including material certificates and pressure test reports.
Frequently Asked Questions
Can Coriolis meters handle LPG custody transfer legally?
Yes. We supply meters with MID certification specifically for LPG service. They include temperature compensation and density measurement, so you can invoice on mass or standard volume.
Are these meters approved for use in Brazil or Latin America?
We help customers comply with INMETRO requirements by supplying certificates and documents needed for local verification. Reach out early in your project so we can prepare the paperwork.
Do I need a flow computer for custody transfer?
Our Coriolis transmitter can output corrected mass flow directly. For billing systems that require a separate flow computer, we provide pulse and digital outputs that connect to OMNI or similar devices.
How often do certified Coriolis meters require recalibration?
Most regulations suggest annual verification. We offer factory recalibration services and can arrange onsite verification using master meters. The meters also include internal diagnostics that signal if zero drift exceeds limits.
Can Silver Instruments supply meters with local language markings?
Yes. We can engrave nameplates in Spanish, Portuguese, Arabic, and other languages. Specify your preference when ordering.
