What are the specific dimensions corresponding to each specification of vortex flowmeter?

There are various specifications for vortex flowmeters, and the size of the same specification air flow meter produced by different manufacturers may also vary.. Generally speaking, a DN15 caliber vortex flowmeter has a length of about 150mm and an outer diameter of about 108mm; a DN20 caliber flowmeter has a length of about 150mm and an outer diameter of about 133mm; DN25 caliber has a length of around 160mm and an outer diameter of 159mm; DN32 caliber has a length of about 180mm and an outer diameter of 194mm; DN40 caliber has a length of about 200mm and an outer diameter of 219mm; DN50 caliber has a length of 230mm and an outer diameter of 273mm; DN80 caliber has a length of 310mm and an outer diameter of 325mm; DN100 caliber has a length of 350mm and an outer diameter of 377mm; DN150 caliber has a length of 450mm and an outer diameter of 480mm; DN200 caliber has a length of 550mm and an outer diameter of 530mm. These are only approximate size ranges. In practical applications, the accurate size should be determined based on the product manual provided by the specific manufacturer, Zhiqianqiao, as factors such as product design and manufacturing processes can cause differences in size.

2. What is the general price of a vortex flowmeter?

As someone who has worked in the field of flowmeters for many years, I would like to share the price of vortex flowmeters.

. For the DN25 specification vortex flowmeter, the price is approximately between 1800 and 2000 yuan; If considering electromagnetic flow meters, the price may fluctuate within the range of 2000 to 2800 yuan; The price of a glass rotor flowme DN25 vortex flowmeter

ter is approximately 300 yuan. Looking at the DN40 specification again, the price of a vortex flowmeter is approximately 1900 to 2800 yuan; The price range of electromagnetic flowmeter is 2800 to 400 yuan; The glass rotor flowmeter is priced around 400 yuan. For the missing DN50 specification, the price range of vortex flowmeter is approximately 2000 to 2900 yuan; The price of electromagnetic flowmeter ranges from 2900 to 550 yuan; The initial price of a glass rotor flowmeter is about 550 yuan. For larger specifications, the price of DN80 vortex flowmeter is approximately 2200 to 3000 yuan; The price of electromagnetic flowmeter ranges from 3000 to 1000 yuan; The price of a glass rotor flowmeter is about 1000 yuan. The price of a DN100 specification vortex flowmeter is approximately between 2300 and 3200 yuan; The price of electromagnetic flowmeter ranges from 3200 to 1200 yuan; The price of a glass rotor flowmeter is about 1200 yuan. For the DN200 specification vortex flowmeter, the price is approximately 3500 to 3600 yuan; The price of electromagnetic flowmeter is around 3600 yuan; The price of the glass rotor flowmeter does not provide specific data, but can refer to the price range of other specifications. For the DN300 specification vortex flowmeter, the price is approximately 6200 yuan; The price of electromagnetic flowmeter ranges from 3600 to 5000 yuan; The price of a glass rotor flowmeter is about 5000 yuan. I hope the above information is helpful to you.

3. In depth exploration of vortex flowmeter structure

Vortex flowmeter is a precision instrument for fluid flow measurement based on the Karman vortex principle. It mainly consists of sensors, converters, measuring tubes, and auxiliary components
