1. Discussion: What flowmeter is used to measure hydrogen? V-cone flowmeter can be used to measure hydrogen. The following is a detailed explanation of its applicability and characteristics: The medium adaptability of V-cone flowmeter. V-cone flowmeter belongs to differential pressure flowmeter, and its core measurement principle is to calculate the flow rate by detecting the differential pressure signal generated when the fluid flows through the conical throttling device. This design enables it to have a wide range of medium compatibility, capable of measuring all gases (including hydrogen, natural gas, air, etc.) and liquids (such as water, oil, etc.), especially suitable for flow monitoring of flammable and explosive gases such as hydrogen. Figure: Schematic diagram of V-cone flowmeter structure (throttling cone and differential pressure detection device). The core advantage of V-cone flowmeter is small pressure loss: the streamlined design of the conical throttling device significantly reduces energy loss when fluid passes through. Compared with conventional orifice flowmeters, pressure loss can be reduced by more than 70%. This characteristic is particularly important for hydrogen measurement, as it can avoid measurement errors caused by changes in hydrogen density due to pressure drops, while reducing system energy consumption. High precision: By optimizing the cone angle and differential pressure signal acquisition method, the measurement accuracy of the V-cone flowmeter can reach ± 0.5%, and the repeatability is better than ± 0.1%. In the hydrogen metering scenario, high precision can ensure the accuracy of energy settlement, process control, and other aspects. Large range: Its range ratio can usually reach 10:1 to 15:1, and a single instrument can cover the wide range measurement needs of hydrogen gas from low flow to high flow, avoiding frequent instrument replacement or parameter adjustment due to flow fluctuations. Strong anti-interference ability: The measurement results of V-cone flowmeter are almost unaffected by parameters such as fluid density, temperature cracking, pressure, etc. The density of hydrogen gas varies significantly with temperature and pressure (for example, the density under standard conditions is 0.0899 kg/m3, and the density increases significantly under high pressure), while the V-cone flowmeter can directly output mass flow rate or standard volume flow rate through a fixed algorithm of differential pressure and cone geometry relationship, without additional compensation. The special considerations for hydrogen measurement and the adaptability of V-cone flow meters are flammable and explosive characteristics: the explosion limit of hydrogen mixed with air is 4% -75% (volume fraction), and the measuring instrument needs to meet explosion-proof requirements. The V-cone flowmeter can adopt an explosion-proof design (such as ExdIICT4 grade), combined with an intrinsic safety smart bundle rise differential pressure transmitter, to ensure safety in extreme working conditions such as hydrogen leakage. Low density and low viscosity: The density of hydrogen is only 1/14 of that of air, and its viscosity is extremely low (0.0105mPa · s at 20 ℃). Conventional flow meters may have measurement errors due to uneven flow velocity distribution or weak signals. The cone structure of the V-cone flowmeter can force the fluid to form a stable flow field, and the strength of the differential pressure signal is independ
